52mm (2-1/16") ViewLine Engine Oil Temperature Pressure Gauge - 150 PSI - White Dial & Bezel

Veratron ViewLine offers a comprehensive modular, modern series of instruments for engine monitoring.

More functions and greater flexibility in installation and design increase the scope for high manufacturing standards and guarantee the highest level of reliability and readability. As the result of ongoing research and development work, we offer an innovative comprehensive standard instrumentation platform which is also available for outboard engine use. ViewLine provides maximum freedom to customize the cockpit and is the natural choice for an attractive price/performance ratio.

The ViewLine 52 mm Gauges are available in black or white dial versions, which are always completed with a round bezel in the identical color.

Interchangeable bezel option.

Features:

8 pole Tyco / Hirschmann MQS plug
+/- 3.6° angle degree accuracy over the entire display range
Operating voltage 8–32 V
Integrated warning alarm
Input signal: standard Ω values
An optional make-point switch can be connected
Reverse polarity protection
Anti-fog double lens
Front side protection rating IP67
52 mm installation diameter
50 mm installation depth

This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.

Specifications:

Box Set: No
Gauge Size: 2-1/16"
Gauge Type: Oil Pressure
Series: ViewLine
Voltage - Input Range (Volts): 8-32v
Box Dimensions: 3"H x 3"W x 4"L WT: 0.3 lbs
UPC: 7640178723177

Veratron 52mm (2-1/16") ViewLine Engine Oil Pressure Gauge - 150 PSI - White Dial Bezel [A2C59514202]
